VLT
®
MICRO
No. Parameter Function Parameter Factory
Name Explanation Value Setting
46 Multi-function d01:Pre-set frequency attained d07
RELAY output d02:Non-zero speed
d03:Over-torque detection
d04:Baseblock indicator
d05:Low-voltage detect
d06:AC drive control mode
d07:Fault indicator
d08:Desired frequency attained
d09:PLC program running
d10:PLC program step complete
d11:PLC completed execution
d12:PLC execution paused
d13:Terminal counter reached
d14:Prelim counter value reached
47 Desired Freq. Desired frequency d0.0 - d400.0 Hz d0.0
Attained attained
48 Potentiometer Potentiometer shift d0.0 - d350 Hz d0.0
Control of output frequency
49 Potentiometer bias d00:Minimum output frequency d00
control corresponds to potentiometer
at 0 V or 4 mA
d01:Initial output frequency set
with a potential bias point,
refer to Pr.50
50 Potentiometer out- d01 - d200% d100
put freq. gain
51 Reverse motion d00:Forward motion only d00
setting d01:Reverse motion enabled
52 Mtr. Operating Motor rated current d30 - d120% d100
Specifications
53 Motor no-load d00 - d99% d40
54 Torque Comp. Auto torque d00 - d10 d02
Setting compensation gain
55 Slip Comp. Slip compensation d0.0 - d10.0 d0.0
56 Specific Output Actual mtr. current d00:Display actual motor current d00
Display or DC Bus voltage d01:Display DC Bus voltage
57 AC Drive Rated Current Indicator d##.#
58 Electronic Select motor d00:Active with standard motor d02
Thermal derating vs. d01:Active with special motor
Overload Relay temperature curves d02:Inactive
65
