14. Using petroleum jelly to retain it, install a new interface O-ring (G42).
15. Using petroleum jelly to retain them, install new interface O-rings (G38 and G36).
16. Install the motor control and/or multifunction block.
17. Install the screws (M22).
18. Torque the screws:
•
78 N•m [57.6 lbf•ft] using a 10 mm internal hex wrench for 60 cm³, 80 cm³, 110 cm³ motors.
•
110 N•m [81 lbf•ft] using a 12 mm internal hex wrench for 160 cm³ and 250 cm³ motors.
Caution
Do not overtorque screws.
Service Manual
Series 51 and 51-1 Motors
Minor repair
60 |
©
Danfoss | March 2016 11008567 | AX00000013en-US0202
