GENERAL INFORMATIONPRODUCT INFORMATIONINTEGRATION INTO SYSTEMORDERING INFORMATION SYSTEM DESIGN
Compressor model DSH240-295-381
MPM
S
SSH
CCSS
LPS
UNIT
CONTROLLER
KM
DGT
CB
Fuses .............................................................................................................F1
Compressor contactor ............................................................................ KM
High pressure safety switch....................................................................HP
Safety pressure switch ........................................................................... LPS
Discharge gas thermistor (embedded in compressor) .................DGT
Compressor motor .................................................................................... M
Motor Protection Module .................................................................. MPM
Thermistor chain (motor and discharge temperature) ...................... S
Surface sump heater .............................................................................. SSH
Thermal magnetic motor circuit breaker............................................ CB
Legends
Provide power supply and electrical protection
44 FRCC.PC.045.A7.02
