Danfoss DSH090 Application Guidelines

GENERAL INFORMATIONPRODUCT INFORMATIONINTEGRATION INTO SYSTEMORDERING INFORMATION SYSTEM DESIGN
Provide power supply and electrical protection
Compressor model DSH485 code 3
1
2
3
L1 L3
L2
7
8
9
L1
L3
L3
L2
L2
S
L1
MPM
MPM
LPS
UNIT
CONTROLLER
KM
KM
CCSS
CB
SSH
Legends
Compressor model DSH485 except code 3
SSH
CONTROL
CIRCUIT
LPS
UNIT
CONTROLLER
SEPARATE
SUPPLY
KM
DGT
MPM
S
CB
Fuses .............................................................................................................F1
Compressor contactor ............................................................................ KM
High pressure safety switch....................................................................HP
Safety pressure switch ........................................................................... LPS
Discharge gas thermistor (embedded in compressor) .................DGT
Compressor motor .................................................................................... M
Motor Protection Module .................................................................. MPM
Thermistor chain (motor and discharge temperature) ...................... S
Surface sump heater .............................................................................. SSH
Thermal magnetic motor circuit breaker............................................ CB
45FRCC.PC.045.A7.02
