Danfoss DSH090 Application Guidelines

GENERAL INFORMATIONPRODUCT INFORMATIONSYSTEM DESIGNINTEGRATION INTO SYSTEMORDERING INFORMATION
Ordering codes
Trio kits By default, DSH tandems and trios are not
factory-built.
To complete an assembly in the field, you will
need:
- Tubings, according to specific outline drawings.
- Manifolding accessory kit indicated below
- Compressors.
For DSH240/295/381/485 you will need in
addition one mounting kit per compressor.
(7777045 for 50Hz application, 120Z0495 for
60Hz)
Trio model Cp1 Cp2 Cp3 Suction from Trio Kit code n° Mounting kit
DSH420 DSH140 DSH140 DSH140
Left
120Z0672
Not needed
Right
DSH483 DSH161 DSH161 DSH161
Left
120Z0684
Right
DSH552 DSH184 DSH184 DSH184
Left
120Z0685
Right
DSH720 DSH240 DSH240 DSH240
Left 120Z0673
7777045 for
50Hz
or
120Z0495 for
60Hz
Right 7777039
DSH885 DSH295 DSH295 DSH295
Left 120Z0673
Right 7777039
DSH1140 DSH381 DSH381 DSH381
Left 120Z0686
Right 120Z0688
DSH1245 DSH381 DSH381 DSH485
Left
7777063
Right
DSH1350 DSH381 DSH485 DSH485
Left
7777063
Right
DSH1455 DSH485 DSH485 DSH485
Left
7777040
Right
=
=
=
=
=
=
=
=
=
For example : Trio DSH1245
- Compressors 1 and 2: DSH381 Code number 120H1130 (Motor code 4/110-240V electronic module/Industrial pack)
- Compressor 3: DSH485 Code number 120H1134 (Motor code 4/110-240V electronic module/Industrial pack)
- Trio kit DSH1245: Code number 7777063
- Three mounting Kits 7777045 (or 120Z0495 if 60Hz application)
For example: Trio DSH420
- Compressor 1, 2 and 3: DSH140 Code number 120H1207
- Trio kit DSH420: Code number 120Z0672
59FRCC.PC.045.A7.02
