Danfoss DSH090 Application Guidelines

GENERAL INFORMATIONPRODUCT INFORMATIONSYSTEM DESIGNINTEGRATION INTO SYSTEMORDERING INFORMATION
Ordering codes
Tandem Model Cp1 Cp2 Suction From Tandem Kit Code No. Mounting kit
DSH180E DSH090 DSH090
Left
120Z0634
Not needed
Right
DSH195U DSH090 DSH105
Left
120Z0694
Right
DSH210U DSH090 DSH120
Left
120Z0694
Right
DSH210E DSH105 DSH105
Left
120Z0634
Right
DSH230U DSH090 DSH140
Left
120Z0694
Right
DSH240E DSH120 DSH120
Left
120Z0634
Right
DSH251U DSH090 DSH161
Left
120Z0694
Right
DSH260U DSH120 DSH140
Left
120Z0692
Right
DSH274U DSH090 DSH184
Left
120Z0693
Right
DSH281U DSH120 DSH161
Left
120Z0692
Right
DSH280E DSH140 DSH140
Left
120Z0634
Right
DSH289U DSH105 DSH184
Left
120Z0693
Right
DSH301U DSH140 DSH161
Left
120Z0692
Right
DSH304U DSH120 DSH184
Left
120Z0694
Right
DSH322E DSH161 DSH161
Left
120Z0634
Right
DSH324U DSH140 DSH184
Left
120Z0694
Right
DSH345U DSH161 DSH184
Left
120Z0694
Right
DSH368E DSH184 DSH184
Left
120Z0634
Right
DSH360X DSH120 DSH240
Left
120Z0709
Right
DSH424X DSH184 DSH240
Left
120Z0709
Right
DSH456X DSH161 DSH295
Left
120Z0709
Right
DSH479X DSH184 DSH295
Left
120Z0709
Right
DSH565X DSH184 DSH381
Left
120Z0709
Right
DSH482 DSH240 DSH240
Left
7777041
7777045 for 50Hz
120z0495 for
60Hz
Right
DSH535 DSH240 DSH295
Left
7777037
Right
DSH590 DSH295 DSH295
Left
7777041
Right
DSH620 DSH240 DSH381
Left
7777048
Right
DSH675 DSH295 DSH381
Left
7777037
Right
DSH725 DSH240 DSH485
Left
120Z0569
Right
DSH760 DSH381 DSH381
Left
7777041
Right
DSH780 DSH295 DSH485
Left
120Z0551
Right
DSH865 DSH381 DSH485
Left
120Z0550
Right
DSH970 DSH485 DSH485
Left
120Z0578
Right
Tandem kits By default, DSH tandems and trios are not
factory-built. To complete an assembly in the
field, you will need:
- Tubings, according to specific outline drawings.
- Manifolding accessory kit indicated below
- Compressors.
For DSH240/295/381/485 you will need in
addition one mounting kit per compressor.
(7777045 for 50Hz application, 120Z0495 for
60Hz)
For example: Tandem DSH535
- Compressor 1: DSH240 Code number 120H1122 (Motor code 4/110-240V electronic module/Industrial pack)
- Compressor 2: DSH295 Code number 120H1126 (Motor code 4/110-240V electronic module/Industrial pack)
- Tandem kit DSH535: Code number 7777037
- Two mounting Kits 7777045 (or 120Z0495 if 60Hz application)
For example: Tandem DSH324
- Compressor 1: DSH140 Code number 120H1207 (Motor code 4 /Industrial pack)
- Compressor 2: DSH184 Code number 120H1223 (Motor code 4 /Industrial pack)
- Tandem kit DSH324 120Z0647
58 FRCC.PC.045.A7.02
