8.1.2 Mains Supply 3x380-480 V AC
Frequency converter PK37 PK75 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5 P11K P15K
Typical shaft output [kW] 0.37 0.75 1.5 2.2 3.0 4.0 5.5 7.5 11.0 15.0
Typical shaft output [hp] 0.5 1.0 2.0 3.0 4.0 5.0 7.5 10.0 15.0 20.0
IP20 frame H1 H1 H1 H2 H2 H2 H3 H3 H4 H4
Max. cable size in terminals
(mains, motor) [mm
2
/AWG]
4/10 4/10 4/10 4/10 4/10 4/10 4/10 4/10 16/6 16/6
Output current - 40 °C ambient temperature
Continuous (3x380-440 V)[A] 1.2 2.2 3.7 5.3 7.2 9.0 12.0 15.5 23.0 31.0
Intermittent (3x380-440 V) [A] 1.3 2.4 4.1 5.8 7.9 9.9 13.2 17.1 25.3 34.0
Continuous (3x440-480 V) [A] 1.1 2.1 3.4 4.8 6.3 8.2 11.0 14.0 21.0 27.0
Intermittent (3x440-480 V) [A] 1.2 2.3 3.7 5.3 6.9 9.0 12.1 15.4 23.1 29.7
Max. input current
Continuous (3x380-440 V) [A] 1.2 2.1 3.5 4.7 6.3 8.3 11.2 15.1 22.1 29.9
Intermittent (3x380-440 V) [A] 1.3 2.3 3.9 5.2 6.9 9.1 12.3 16.6 24.3 32.9
Continuous (3x440-480 V) [A] 1.0 1.8 2.9 3.9 5.3 6.8 9.4 12.6 18.4 24.7
Intermittent (3x440-480 V) [A] 1.1 2.0 3.2 4.3 5.8 7.5 10.3 13.9 20.2 27.2
Max. mains fuses
See 5.2.3 Fuses and Circuit Breakers
Estimated power loss [W],
best case/typical
1)
13/15 16/21 46/57 46/58 66/83 95/118 104/131 159/198 248/274 353/379
Weight enclosure IP20 [kg] 2.0 2.0 2.1 3.3 3.3 3.4 4.3 4.5 7.9 7.9
Efficiency [%],
best case/typical
1)
97.8/97.3 98.0/97.6 97.7/97.2 98.3/97.9 98.2/97.8 98.0/97.6 98.4/98.0 98.2/97.8 98.1/97.
9
98.0/97.
8
Output current - 50 °C ambient temperature
Continuous (3x380-440 V) [A] 1.04 1.93 3.7 4.85 6.3 8.4 10.9 14.0 20.9 28.0
Intermittent (3x380-440 V) [A] 1.1 2.1 4.07 5.4 6.9 9.2 12.0 15.4 23.0 30.8
Continuous (3x440-480 V) [A] 1.0 1.8 3.4 4.4 5.5 7.5 10.0 12.6 19.1 24.0
Intermittent (3x440-480 V) [A] 1.1 2.0 3.7 4.8 6.1 8.3 11.0 13.9 21.0 26.4
Table 8.2 3x380-480 V AC, PK37-P11K, H1-H4
1) At rated load conditions
General Specifications and ...
VLT
®
HVAC Basic Drive FC 101 Design Guide
MG18C502 - Rev. 2013-09-06 99
8 8
