Danfoss FC 101 Design Guide

8.4 dU/Dt
Cable length [m] AC line voltage [V] Rise time [usec]
V
peak
[kV]
dU/dt [kV/usec]
200 V 0.25 kW
5 240 0,121 0,498 3.256
25 240 0,182 0,615 2,706
50 240 0,258 0,540 1.666
200 V 0.37 kW
5 240 0,121 0,498 3.256
25 240 0,182 0,615 2,706
50 240 0,258 0,540 1.666
200 V 0.75 kW
5 240 0,121 0,498 3.256
25 240 0,182 0,615 2,706
50 240 0,258 0,540 1.666
200 V 1.5 kW
5 240 0,121 0,498 3.256
25 240 0,182 0,615 2,706
50 240 0,258 0,540 1.666
200 V 2.2 kW
5 240 0,18 0,476 2.115
25 240 0,230 0,615 2.141
50 240 0,292 0,566 1.550
200 V 3.7 kW
5 240 0,168 0,570 2.714
25 240 0,205 0,615 2.402
50 240 0,252 0,620 1.968
200 V 5.5 kW
5 240 0,128 0,445 2781
25 240 0,224 0,594 2121
50 240 0,328 0,596 1454
200 V 7.5 kW
5 240 0,18 0,502 2244
25 240 0,22 0,598 2175
50 240 0,292 0,615 1678
200 V 11 kW
36 240 0,176 0,56 2545
50 240 0,216 0,599 2204
400 V 0.37 kW
5 400 0,160 0,808 4.050
25 400 0,240 1.026 3.420
50 400 0,340 1.056 2.517
400 V 0.75 kW
5 400 0,160 0,808 4.050
25 400 0,240 1.026 3.420
50 400 0,340 1.056 2.517
400 V 1.5 kW
5 400 0,160 0,808 4.050
25 400 0,240 1.026 3.420
50 400 0,340 1.056 2.517
400 V 2.2 kW
5 400 0,190 0,760 3.200
25 400 0,293 1.026 2.801
50 400 0,422 1.040 1.971
400 V 3.0 kW
5 400 0,190 0,760 3.200
25 400 0,293 1.026 2.801
50 400 0,422 1.040 1.971
400 V 4.0 kW
5 400 0,190 0,760 3.200
25 400 0,293 1.026 2.801
50 400 0,422 1.040 1.971
400 V 5.5 kW
5 400 0,168 0,81 3.857
25 400 0,239 1.026 3.434
50 400 0,328 1,05 2.560
400 V 7.5 kW
5 400 0,168 0,81 3.857
25 400 0,239 1.026 3.434
50 400 0,328 1,05 2.560
