Danfoss FC 101 Design Guide

3 Selection
3.1 Options and Accessories
3.1.1 Local Control Panel (LCP)
Ordering no. Description
132B0200 LCP for all IP20 units
Table 3.1 Ordering Number
Enclosure IP55 front
Max. cable length to unit 10 ft (3 m)
Communication std. RS-485
Table 3.2 Technical Data
3.1.2
Mounting of LCP in Panel Front
Step 1
Fit gasket on LCP.
130BB775.11
Status
Main
Menu
Quick
Menu
Menu
B
a
c
k
Com.
Status
Main
Menu
Quick
Menu
Hand
On
OK
Menu
O
Reset
Auto
On
Alarm
Warn.
On
Com.
Alarm
Warn.
On
B
a
c
k
Hand
OK
O
Reset
Auto
On On
Illustration 3.1 Fit Gasket
Step 2
Place LCP on panel, see dimensions of hole on
Illustration 3.2.
130BB776.11
Gasket
R1.5 +_ 0.5
62.5 +_ 0.2
Panel cut out
Panel Thickness: 1~3mm
86 +_ 0.2
LCP
Panel
Status
Main
Menu
Quick
Menu
Menu
Com.
Alarm
Warn.
On
Hand
On
OK
O
Reset
Auto
On
B
a
c
k
Illustration 3.2 Place LCP on Panel
Step 3
Place bracket on back of the LCP, then slide down.
Tighten screws and connect cable female side to LCP.
130BB777.10
Illustration 3.3 Place Bracket on LCP
Selection
VLT
®
HVAC Basic Drive FC 101 Design Guide
MG18C502 - Rev. 2013-09-06 41
3 3

Danfoss FC 101 Specifications

General

Model	FC 101
Manufacturer	Danfoss
Protection Class	IP20
Relative Humidity	95% (non-condensing)
Communication Interface	RS-485
