Danfoss FC 102

Mains Supply 3x380-480 V AC - Normal overload 110% for 1 minute
Frequency converter
Typical Shaft Output [kW]
P11K
11
P15K
15
P18K
18.5
P22K
22
P30K
30
P37K
37
P45K
45
P55K
55
P75K
75
P90K
90
Typical Shaft Output [hp] at 460 V 15 20 25 30 40 50 60 75 100 125
IP20/Chassis
(B3+4 and C3+4 may be converted to IP21 using a
conversion kit (Contact Danfoss)
B3 B3 B3 B4 B4 B4 C3 C3 C4 C4
IP21/NEMA 1 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2
IP55/NEMA 12 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2
IP66/NEMA 12 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2
Output current
130BA058.10
Continuous (3x380-439 V)
[A]
24 32 37.5 44 61 73 90 106 147 177
Intermittent (3x380-439 V)
[A]
26.4 35.2 41.3 48.4 67.1 80.3 99 117 162 195
Continuous (3x440-480 V)
[A]
21 27 34 40 52 65 80 105 130 160
Intermittent (3x440-480 V)
[A]
23.1 29.7 37.4 44 61.6 71.5 88 116 143 176
Continuous kVA (400 V AC)
[kVA]
16.6 22.2 26 30.5 42.3 50.6 62.4 73.4 102 123
Continuous kVA 460 V AC)
[kVA]
16.7 21.5 27.1 31.9 41.4 51.8 63.7 83.7 104 128
Max. cable size:
(mains, motor, brake)
[mm
2
/
AWG]
2)
10/7 35/2
50/1/0
(B4=35/2)
95/
4/0
120/
MCM2
50
With mains disconnect
switch included:
16/6 35/2 35/2 70/3/0
185/
kcmil3
50
Max. input current
130BA057.10
Continuous (3x380-439 V)
[A]
22 29 34 40 55 66 82 96 133 161
Intermittent (3x380-439 V)
[A]
24.2 31.9 37.4 44 60.5 72.6 90.2 106 146 177
Continuous (3x440-480 V)
[A]
19 25 31 36 47 59 73 95 118 145
Intermittent (3x440-480 V)
[A]
20.9 27.5 34.1 39.6 51.7 64.9 80.3 105 130 160
Max. pre-fuses
1)
[A]
63 63 63 63 80 100 125 160 250 250
Environment
Estimated power loss
at rated max. load [W]
4)
278 392 465 525 698 739 843 1083 1384 1474
Weight enclosure IP20 [kg] 12 12 12 23.5 23.5 23.5 35 35 50 50
Weight enclosure IP21 [kg] 23 23 23 27 27 45 45 45 65 65
Weight enclosure IP55 [kg] 23 23 23 27 27 45 45 45 65 65
Weight enclosure IP66 [kg] 23 23 23 27 27 45 45 45 65 65
Efficiency
3)
0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.99
Table 9.4 Mains Supply 3x380-480 V AC
