Danfoss FC 102 Design Guide

6.2.4 Fuse Tables
Enclosure
type
Power [kW] Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Moeller
Max trip level [A]
A2 1.1-2.2 gG-10 (1.1-1.5)
gG-16 (2.2)
gG-25 PKZM0-25 25
A3 3.0-3.7 gG-16 (3)
gG-20 (3.7)
gG-32 PKZM0-25 25
B3 5.5-11 gG-25 (5.5-7.5)
gG-32 (11)
gG-63 PKZM4-50 50
B4 15-18 gG-50 (15)
gG-63 (18)
gG-125 NZMB1-A100 100
C3 22-30 gG-80 (22)
aR-125 (30)
gG-150 (22)
aR-160 (30)
NZMB2-A200 150
C4 37-45 aR-160 (37)
aR-200 (45)
aR-200 (37)
aR-250 (45)
NZMB2-A250 250
A4 1.1-2.2 gG-10 (1.1-1.5)
gG-16 (2.2)
gG-32 PKZM0-25 25
A5 0.25-3.7 gG-10 (0.25-1.5)
gG-16 (2.2-3)
gG-20 (3.7)
gG-32 PKZM0-25 25
B1 5.5-11 gG-25 (5.5)
gG-32 (7.5-11)
gG-80 PKZM4-63 63
B2 15 gG-50 gG-100 NZMB1-A100 100
C1 18-30 gG-63 (18.5)
gG-80 (22)
gG-100 (30)
gG-160 (18.5-22)
aR-160 (30)
NZMB2-A200 160
C2 37-45 aR-160 (37)
aR-200 (45)
aR-200 (37)
aR-250 (45)
NZMB2-A250 250
Table 6.19 200-240 V, Enclosure Types A, B and C
Electrical Installation Design Guide
96 Danfoss A/S © Rev. 06/2014 All rights reserved. MG11BC02
