Danfoss FC 102 Design Guide

Enclosure
type
Power [kW] Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker Moeller
Max trip level [A]
A2 1.1-4.0 gG-10 (1.1-3)
gG-16 (4)
gG-25 PKZM0-25 25
A3 5.5-7.5 gG-16 gG-32 PKZM0-25 25
B3 11-18 gG-40 gG-63 PKZM4-50 50
B4 22-37 gG-50 (22)
gG-63 (30)
gG-80 (37)
gG-125 NZMB1-A100 100
C3 45-55 gG-100 (45)
gG-160 (55)
gG-150 (45)
gG-160 (55)
NZMB2-A200 150
C4 75-90 aR-200 (75)
aR-250 (90)
aR-250 NZMB2-A250 250
A4 1.1-4 gG-10 (1.1-3)
gG-16 (4)
gG-32 PKZM0-25 25
A5 1.1-7.5 gG-10 (1.1-3)
gG-16 (4-7.5)
gG-32 PKZM0-25 25
B1 11-18.5 gG-40 gG-80 PKZM4-63 63
B2 22-30 gG-50 (22)
gG-63 (30)
gG-100 NZMB1-A100 100
C1 37-55 gG-80 (37)
gG-100 (45)
gG-160 (55)
gG-160 NZMB2-A200 160
C2 75-90 aR-200 (75)
aR-250 (90)
aR-250 NZMB2-A250 250
Table 6.20 380-480 V, Enclosure Types A, B and C
Enclosure
type
Power [kW] Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Moeller
Max trip level [A]
A3 5.5-7.5 gG-10 (5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B3 11-18 gG-25 (11)
gG-32 (15-18)
gG-63 PKZM4-50 50
B4 22-37 gG-40 (22)
gG-50 (30)
gG-63 (37)
gG-125 NZMB1-A100 100
C3 45-55 gG-63 (45)
gG-100 (55)
gG-150 NZMB2-A200 150
C4 75-90 aR-160 (75)
aR-200 (90)
aR-250 NZMB2-A250 250
A5 1.1-7.5 gG-10 (1.1-5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B1 11-18 gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-80 PKZM4-63 63
B2 22-30 gG-50 (22)
gG-63 (30)
gG-100 NZMB1-A100 100
C1 37-55 gG-63 (37)
gG-100 (45)
aR-160 (55)
gG-160 (37-45)
aR-250 (55)
NZMB2-A200 160
C2 75-90 aR-200 (75-90) aR-250 NZMB2-A250 250
Table 6.21 525-600 V, Enclosure Types A, B and C
Electrical Installation
Design Guide
MG11BC02 Danfoss A/S © Rev. 06/2014 All rights reserved. 97
6 6
