4 How to Order
4.1 Ordering Form
4.1.1 Drive Configurator
It is possible to design a frequency converter according to
the application requirements by using the ordering
number system.
Order the frequency converter as either standard or with
integral options by sending a type code string describing
the product a to the local Danfoss sales office, i.e.:
FC-102P18KT4E21H1XGCXXXSXXXXAGBKCXXXXDX
The meaning of the characters in the string can be located
in the pages containing the ordering numbers in chapter 3
Selection. In the example above, a Profibus LON works
option and a General purpose I/O option is included in the
frequency converter.
Ordering numbers for frequency converter standard
variants can also be located in chapter 4 How to Order.
Configure the right frequency converter for the right
application and generate the type code string in the
Internet-based Drive Configurator. The Drive Configurator
automatically generates an 8-digit sales number to be
delivered to the local sales office.
Furthermore, establish a project list with several products
and send it to a Danfoss sales representative.
The Drive Configurator can be found on the global
Internet site: www.danfoss.com/drives.
Example of Drive Configurator interface set-up:
The numbers shown in the boxes refer to the letter/figure
number of the Type Code String - read from left to right.
Product groups
1-3
Frequency converter series 4-6
Power rating 8-10
Phases 11
Mains Voltage 12
Enclosure 13-15
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter 16-17
Brake 18
Display (LCP) 19
Coating PCB 20
Mains option 21
Adaptation A 22
Adaptation B 23
Software release 24-27
Software language 28
A options 29-30
B options 31-32
C0 options, MCO 33-34
C1 options 35
C option software 36-37
D options 38-39
Table 4.1 Example of Drive Configurator Interface Set-up
How to Order Design Guide
MG11BC02 Danfoss A/S © Rev. 06/2014 All rights reserved. 65
4 4
