4.1.2 Type Code String Low and Medium Power
F C - P T H
130BA052.14
X S A B CX X X X
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 302221 23 272524 26 28 29 31 373635343332 38 39
X0 D
Illustration 4.1 Type Code String
Description Pos. Possible choice
Product group & FC
Series
1-6 FC 102
Power rating 8-10 1.1- 90 kW (P1K1 - P90K)
Number of phases 11 3 phases (T)
Mains voltage 11-12
T 2: 200-240 V AC
T 4: 380-480 V AC
T 6: 525-600 V AC
T 7: 525-690 V AC
Enclosure 13-15
E20: IP20
E21: IP21/NEMA Type 1
E55: IP55/NEMA Type 12
E66: IP66
P21: IP21/NEMA Type 1 w/
backplate
P55: IP55/NEMA Type 12 w/
backplate
Z55: A4 Frame IP55
Z66: A4 Frame IP66
RFI filter 16-17
H1: RFI filter class A1/B
H2: RFI filter class A2
H3: RFI filter class A1/B
(reduced cable length)
Hx: No RFI filter
Brake 18
X: No brake chopper included
B: Brake chopper included
T: Safe Stop
U: Safe + brake
Display 19
G: Graphical Local Control
Panel (GLCP)
N: Numeric Local Control
Panel (NLCP)
X: No Local Control Panel
Coating PCB 20
X. No coated PCB
C: Coated PCB
Mains option 21
X: No Mains disconnect
switch and Load Sharing
1: With Mains disconnect
switch (IP55 only)
8: Mains disconnect and Load
Sharing
D: Load Sharing
See Chapter 9 for max. cable
sizes.
Description Pos. Possible choice
Adaptation 22
X: Standard cable entries
O: European metric thread in
cable entries (A4, A5, B1, B2
only)
S: Imperial cable entries (A5,
B1, B2 only)
Adaptation 23 Reserved
Software release 24-27 Actual software
Software language 28
A options 29-30
AX: No options
A0: MCA 101 Profibus DP V1
A4: MCA 104 DeviceNet
AG: MCA 108 Lonworks
AJ: MCA 109 BACnet gateway
AL: MCA 120 Profinet
AN: MCA 121 EtherNet/IP
AQ: MCA 122 Modbus TCP
B options 31-32
BX: No option
BK: MCB 101 General purpose
I/O option
BP: MCB 105 Relay option
BO: MCB 109 Analog I/O
option
B2: MCB 112 PTC Thermistor
Card
B4: MCB 114 Sensor input
option
C0 options MCO 33-34 CX: No options
C1 options 35 X: No options
C option software 36-37 XX: Standard software
D options 38-39
DX: No option
D0: 24 V back- up
Table 4.2 Type Code Description
