Danfoss FC 102

I
AHF,N
[A] Typical Motor Used [hp] Danfoss Ordering Number
Frequency converter size
AHF 005 AHF 010
10 1.5-7.5 130B2538 130B2539 P1K1-P5K5
19 10-15 175G6612 175G6634 P7K5-P11K
26 20 175G6613 175G6635 P15K
35 25-30 175G6614 175G6636 P18K-P22K
43 40 175G6615 175G6637 P30K
72 50-60 175G6616 175G6638 P37K-P45K
101 75 175G6617 175G6639 P55K
144 100-125 175G6618 175G6640 P75K-P90K
180 150 175G6619 175G6641 P110
217 200 175G6620 175G6642 P132
289 250 175G6621 175G6643 P160
370 350 175G6690 175G6693 P200
434 350 2x175G6620 2x175G6642 P250
506 450 175G6620 + 175G6621 175G6642 + 175G6643 P315
578 500 2x 175G6621 2x 175G6643 P355
648 550-600 2x175G6689 2x175G6692 P400
694 600 175G6689 + 175G6690 175G6692 + 175G6693 P450
740 650 2x175G6690 2x175G6693 P500
Table 4.8 440-480 V AC, 60 Hz
Matching the frequency converter and filter is pre-calculated based on 400 V/480 V and on a typical motor load (4 pole)
and 110 % torque.
I
AHF,N
[A] Typical Motor Used [kW] Danfoss Ordering Number
Frequency converter size
AHF 005 AHF 010
10 1.1-7.5 175G6644 175G6656 P1K1-P7K5
19 11 175G6645 175G6657 P11K
26 15-18.5 175G6646 175G6658 P15K-P18K
35 22 175G6647 175G6659 P22K
43 30 175G6648 175G6660 P30K
72 37-45 175G6649 175G6661 P45K-P55K
101 55 175G6650 175G6662 P75K
144 75-90 175G6651 175G6663 P90K-P110
180 110 175G6652 175G6664 P132
217 132 175G6653 175G6665 P160
289 160-200 175G6654 175G6666 P200-P250
324 250 175G6655 175G6667 P315
397 315 175G6652 + 175G6653 175G6641 + 175G6665 P400
434 355 2x175G6653 2x175G6665 P450
506 400 175G6653 + 175G6654 175G6665 + 175G6666 P500
578 450 2X 175G6654 2X 175G6666 P560
613 500 175G6654 + 175G6655 175G6666 + 175G6667 P630
Table 4.9 500-525 V AC, 50 Hz
How to Order
