4.2.3 Ordering Numbers: Sine Wave Filter Modules, 200-500 V AC
Frequency Converter Size
Minimum switching
frequency [kHz]
Maximum
output
frequency [Hz]
Part No. IP20 Part No. IP00
Rated filter current
at 50 Hz [A]
200-240 [V
AC]
380-440 [V
AC]
440-480 [V
AC]
P1K1 P1K1 5 120 130B2441 130B2406 4.5
P1K5 P1K5 5 120 130B2441 130B2406 4.5
P2K2 P2K2 5 120 130B2443 130B2408 8
P1K5 P3K0 P3K0 5 120 130B2443 130B2408 8
P4K0 P4K0 5 120 130B2444 130B2409 10
P2K2 P5K5 P5K5 5 120 130B2446 130B2411 17
P3K0 P7K5 P7K5 5 120 130B2446 130B2411 17
P4K0 5 120 130B2446 130B2411 17
P5K5 P11K P11K 4 100 130B2447 130B2412 24
P7K5 P15K P15K 4 100 130B2448 130B2413 38
P18K P18K 4 100 130B2448 130B2413 38
P11K P22K P22K 4 100 130B2307 130B2281 48
P15K P30K P30K 3 100 130B2308 130B2282 62
P18K P37K P37K 3 100 130B2309 130B2283 75
P22K P45K P55K 3 100 130B2310 130B2284 115
P30K P55K P75K 3 100 130B2310 130B2284 115
P37K P75K P90K 3 100 130B2311 130B2285 180
P45K P90K P110 3 100 130B2311 130B2285 180
P110 P132 3 100 130B2312 130B2286 260
P132 P160 3 100 130B2313 130B2287 260
P160 P200 3 100 130B2313 130B2287 410
P200 P250 3 100 130B2314 130B2288 410
P250 P315 3 100 130B2314 130B2288 480
P315 P315 2 100 130B2315 130B2289 660
P355 P355 2 100 130B2315 130B2289 660
P400 P400 2 100 130B2316 130B2290 750
P450 2 100 130B2316 130B2290 750
P450 P500 2 100 130B2317 130B2291 880
P500 P560 2 100 130B2317 130B2291 880
P560 P630 2 100 130B2318 130B2292 1200
P630 P710 2 100 130B2318 130B2292 1200
P710 P800 2 100 2x130B2317 2x130B2291 1500
P800 P1M0 2 100 2x130B2317 2x130B2291 1500
P1M0 2 100 2x130B2318 2x130B2292 1700
Table 4.11 Mains Supply 3x200 to 480 V AC
When using Sine-wave filters, the switching frequency should comply with filter specifications in 14-01 Switching Frequency.
NOTICE
See also Output Filter Design Guide.
How to Order Design Guide
MG11BC02 Danfoss A/S © Rev. 06/2014 All rights reserved. 73
