Danfoss FC 102 Design Guide

4.2.6 Ordering Numbers: dU/dt Filters, 525-600/690 V AC
Frequency converter Size
Minimum switching
frequency [kHz]
Maximum output
frequency [Hz]
Part No. IP20 Part No. IP00
Rated filter current at 50
Hz [A]
525-600 [V AC] 690 [V AC]
P1K1 4 100 130B2423 130B2414 28
P1K5 4 100 130B2423 130B2414 28
P2K2 4 100 130B2423 130B2414 28
P3K0 4 100 130B2423 130B2414 28
P4K0 4 100 130B2424 130B2415 45
P5K5 4 100 130B2424 130B2415 45
P7K5 3 100 130B2425 130B2416 75
P11K 3 100 130B2425 130B2416 75
P15K 3 100 130B2426 130B2417 115
P18K 3 100 130B2426 130B2417 115
P22K 3 100 130B2427 130B2418 165
P30K 3 100 130B2427 130B2418 165
P37K P45K 3 100 130B2425 130B2416 75
P45K P55K 3 100 130B2425 130B2416 75
P55K P75K 3 100 130B2426 130B2417 115
P75K P90K 3 100 130B2426 130B2417 115
P90K P110 3 100 130B2427 130B2418 165
P132 2 100 130B2427 130B2418 165
P160 2 100 130B2428 130B2419 260
P200 2 100 130B2428 130B2419 260
P250 2 100 130B2429 130B2420 310
P315 2 100 130B2238 130B2235 430
P400 2 100 130B2238 130B2235 430
P450 2 100 130B2239 130B2236 530
P500 2 100 130B2239 130B2236 530
P560 2 100 130B2274 130B2280 630
P630 2 100 130B2274 130B2280 630
P710 2 100 130B2430 130B2421 765
P800 2 100 130B2431 130B2422 1350
P900 2 100 130B2431 130B2422 1350
P1M0 2 100 130B2431 130B2422 1350
P1M2 2 100 130B2431 130B2422 1350
P1M4 2 100 2x130B2430 2x130B2421 1530
Table 4.14 Mains supply 3x525 to 3x690 V AC
NOTICE
See also Output Filter Design Guide.
4.2.7 Ordering Numbers: Brake Resistors
NOTICE
See Brake Resistor Design Guide.
How to Order Design Guide
76 Danfoss A/S © Rev. 06/2014 All rights reserved. MG11BC02
