Danfoss FC 300 Operating Instruction

FC 300 Operating Instructions
How to Programme
" 34-** MCO Data Readouts
Par.
No.
#
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
34-0* PCD Write Par.
34-01PCD 1 Write to MCO 0 All set-ups TRUE 0 Uint16
34-02PCD 2 Write to MCO 0 All set-ups TRUE 0 Uint16
34-03PCD 3 Write to MCO 0 All set-ups TRUE 0 Uint16
34-04PCD 4 Write to MCO 0 All set-ups TRUE 0 Uint16
34-05PCD 5 Write to MCO 0 All set-ups TRUE 0 Uint16
34-06PCD 6 Write to MCO 0 All set-ups TRUE 0 Uint16
34-07PCD 7 Write to MCO 0 All set-ups TRUE 0 Uint16
34-08PCD 8 Write to MCO 0 All set-ups TRUE 0 Uint16
34-09PCD 9 Write to MCO 0 All set-ups TRUE 0 Uint16
34-10PCD 10 Write to MC O 0 All set- ups T RUE 0 Uint 16
34-2* PCD R ea d Par.
34-21PCD 1 Read from MCO 0 All set-ups TRUE 0 Uint16
34-22PCD 2 Read from MCO 0 All set-ups TRUE 0 Uint16
34-23PCD 3 Read from MCO 0 All set-ups TRUE 0 Uint16
34-24PCD 4 Read from MCO 0 All set-ups TRUE 0 Uint16
34-25PCD 5 Read from MCO 0 All set-ups TRUE 0 Uint16
34-26PCD 6 Read from MCO 0 All set-ups TRUE 0 Uint16
34-27PCD 7 Read from MCO 0 All set-ups TRUE 0 Uint16
34-28PCD 8 Read from MCO 0 All set-ups TRUE 0 Uint16
34-29PCD 9 Read from MCO 0 All set-ups TRUE 0 Uint16
34-30PCD 10 Read from MCO 0 All set-ups TRUE 0 Uint16
34-4* Inputs & O utputs
34-40Digital Inputs 0 All set-ups TRUE 0 Uint16
34-41Digital Outputs 0 All set-ups TRUE 0 Uint16
34-5* P rocess Data
34-50Actual Position 0 All set-ups TRUE 0 Int32
34-51Commanded Position 0 All set-ups TRUE 0 Int32
34-52Actual Master Position 0 All set-ups TRUE 0 Int32
34-53Slave Index Position 0 All set-ups TRUE 0 In t32
34-54 Master Index Position 0 All set-ups TRUE 0 Int32
34-55Curve Position 0 All set-ups TRUE 0 Int32
34-56Track Error 0 All set-ups TRUE 0 Int32
34-57Synchronizing Error 0 All set-ups TRUE 0 Int32
34-58Actual Velocity 0 All set-ups TRUE 0 Int32
34-59ActualMasterVelocity 0 Allset-ups TRUE 0 Int32
34-60Synchronizing Status 0 All set-ups TRUE 0 Int32
34-61Axis Status 0 All set-ups TRUE 0 Int32
34-62Program Status 0 All set-ups TRUE 0 Int32
34-7* Diagnosis readouts
34-70MCO Alarm Word 1 0 All set-ups FALSE 0 Uint32
34-71MCO Alarm Word 2 0 All set-ups FALSE 0 Uint32
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
65
MG.33.A7.02 - VLT is a registered Danfoss trademark
