Danfoss FC 300 Operating Instruction

FC 300 Operating Instructions
How to Install
" About H ow to Install
This chapter covers mechanical and electrical installations to and from power
terminals and control card terminals.
Electrical installation of options is described in the cor
responding Instructions and Design Guide MG33.BX.YY.
" How to Get Started
FC 300 AutomationDrive is designed to achieve
a quick and EMC-correct installation by follow
ing
the steps described below.
Read the safety instructions before
installing the unit.
Mechanical Installation
• Mechanical mounting
Electrical Installation
• Connection to M ains and Protecting Earth
• Motor connection and cables
• Fuses and circuit breakers
• Control terminals - cables
Quick setup
• Local Control Panel, LCP
• Automatic Motor Adaptation, AMA
• Programming
Frame size is depending on enclosure type,
power range and mains voltage
Diagram showing basic installation including mains, motor,
start/stop key, and potentiometer for speed adjustment.
11
MG.33.A7.02 - VLT is a registered Danfoss trademark
