Danfoss FC 300 Operating Instruction

FC 300 Operating Instructions
How to Programme
Parameter Lists
Changes during operation
”TRUE” means that the parameter can be changed while the frequency converter is in operation and
“FALSE” means that the it must be stopped before a change can be made.
4
-Set-up
’All set-up’: the parameters can be set individually i n each of the four set-ups, i.e. one
single parameter can have four different data values.
’1 set-up’: data value will be the same in all set-ups.
C
onversion i ndex
This number refers to a conversion figure used when writing or reading by means of a frequency converter.
Conv. index 100 67 6 5 4 3 2 1 0 -1 -2 -3 -4 -5 -6
Conv. factor 1 1/60 1000000 100000 10000 1000 100 10 1 0.1 0.01 0.001 0.0001 0.00001 0.000001
Data type Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4
Integer 32 Int32
5 Unsigned 8 Uint8
6
Unsigned 16 Uint16
7 Unsigned 32 Uint32
9
Visible String VisStr
33 Normalized value 2 bytes N2
35
Bit sequence of 16 b oolean variables V2
54 Time difference w/o date TimD
See the FC 300 Design Guide for further inform ation about data types 3 3, 35 and 54.
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
39
MG.33.A7.02 - VLT is a registered Danfoss trademark
