Safety Instructions and General Warning
" Before Commencing Repair Work
1. Disconnect FC 30 0 from mains
2. Disconnect DC bus terminals 88 an d 89
3. Wait for discharge of the DC-link. See period of time on the warning label.
4. Remove motor cable
" Avoid Unintend ed Start
While FC 300 is connected to mains, the motor can be started/stoppe d u sing d igit al commands,
bus commands, references or via the Local Control Panel (LCP).
• Disconnect the FC 300 from ma ins whenever personal safety considerations make
it necessary to avoid unintended start.
• To avoid unintended start, always activate the [OFF] key before changing parameters.
• An electronic fault, temporary overload, a fault in the mains supply, or lost motor connection
may cause a stopp ed motor to start. FC 300 with Safe St op (i.e. FC301 in A1 enclosure
and FC302) provides a certain degree of protection against such unintended start, if the
Safe Stop Term inal 37 is on low voltage level or dis connected.
" Safe Stop of FC 30 0
The FC 302, and also the FC301 in A1 enclosure,
can p erform the safety function Safe Torque Off
(As defined by draft CD IEC 61800-5-2) or Stop
Category 0 (as defin ed in EN 60204-1).
FC 301 A1 enclosure: When Safe Stop is included
in the d rive position 18 of Type Code must
be either T or U. If position 18 is B or X Safe
Stop Terminal 37 is not included!
Example:
Type Code for FC 301 A1 with Safe Stop:
FC-301PK75T4Z20H4TGCXXXSXXXXA0BXCXXXXD0
It is designed and app roved suitable for the
requirements of S afety Category 3 in EN 954-1.
This functionality is called S afe Stop. Prior to
integration and use of Safe Stop in an installation,
a thorough risk analysis on the installation m u st
be carrie d out in order to d etermine whether th
e
Safe Stop functionality and safety category are
appropriate and sufficient. In order to install and
use the Safe Stop function in accordance wi
th the
requirements of S afety Category 3 in EN 954-1,
the related in form ation and instructions of the FC
300 Design Guide MG.33.BX.YY m ust be
followed!
The information and instructions of t he Operating
Instructions are not sufficient for a correct and
safe use of the Safe Stop function
ality!
9
MG.33.A7.02 - VLT is a registered Danfoss trademark
