Danfoss FC 300 Operating Instruction

FC 300 Operating Instructions
How to Programme
" Quick Setup
0-01 Language
Option:
*
English (ENGLISH) [0]
German (DEUTSCH) [1]
French (FRANCAIS) [2]
Danish (DANSK) [3]
Spanish (ESPANOL) [4]
Italian (ITALIA NO) [5]
Chinese (CHINESE) [10]
Finnish (FINNISH) [20]
English US (ENGLISH US) [22]
Greek (GREEK) [27]
Portuguese (PORTUGUESE) [28]
Slovenian (SLOVENIAN) [36]
Korean (KOREAN) [39]
Japanese (JAPANESE) [40]
Turkish (TURKISH) [41]
Traditional Chinese [42]
Bulgarian [43]
Serbian [44]
Romanian (ROMANIAN) [45]
Hungarian (HUNGARIAN) [46]
Czech [47]
Polish (POLISH) [48]
Russian [49]
Thai [50]
Bahasa Indonesian (BAHASA
INDONESIAN) [51]
Function:
Defines the language to be used in display.
The frequency converter can be delivered with
4 various language packages. English and
German are included in all packages. E ng lish
cannot be erased or manipulated.
Language package 1 consists of:
English, German, French, Danish, Spanish,
Italian and Finnish.
Language package 2 consists of:
English, German, Chinese, Korean, Japanese,
Thai and Bahasa Indonesian.
Language package 3 consists of:
English, German, Slovenian, Bulgarian, Serbian,
Romanian, Hungarian, Czech and Russian.
Language package 4 consists of:
English, G erm an, Spanish, English US, Greek,
Brazilian Portuguese, Turkish and Polish.
1-20 Motor Power [kW]
Range:
Size dependent [M-TYPE]
Function:
Enter the nominal motor power in kW according
to the motor nameplate data. The default value
corresponds to the nominal rated outp ut of the unit.
This parameter cannot be adjusted while
the motor is running.
1-22 Motor V oltage
Range:
200-600 V [M-TYPE]
Function:
Enter the nominal motor voltage according to
the motor nameplate data. The default value
corresponds to the nom inal rated output of
the unit. This parameter cannot be adjusted
while the motor is running.
1-23 Motor Frequency
Option:
*
50 Hz (50 HZ) [50]
60 Hz (60 HZ) [60]
Min - Max motor frequency: 20 - 300 Hz
Function:
Select the m otor frequency value from the motor
nameplate data. Alternatively, set t he value for
motor f requency to be infinitely variable. If a value
differentfrom50Hzor60Hzisselected,itis
necessary to adapt the load independent settings
in par. 1-50 to 1-53. For 87 Hz operation with
230/400 V motors, set the nameplate data for
230V/50Hz. Adaptpar. 4-13Motor Speed High
Limit [RPM) and par. 3-03 Maximum Reference
to the 87 Hz application. This parameter cannot
be adjusted while the motor is running.
1-24 Motor C urrent
Range:
Motor type dependent.
Function:
Enter the nominal motor current value from
the motor nameplate data. The data are
used for calculating torque, motor protection
etc. This parameter cannot be adjusted
while the motor is running.
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
36
MG.33.A7.02 - VLT is a registered Danfoss trademark
