Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
33-5* I/O Configuration
33-50 Terminal X57/1 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-51 Terminal X57/2 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-52 Terminal X57/3 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-53 Terminal X57/4 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-54 Terminal X57/5 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-55 Terminal X57/6 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-56 Terminal X57/7 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-57 Terminal X57/8 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-58 Terminal X57/9 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-59Terminal X57/10 Digital Input [0] No fun ction 2 set-ups TRU E - Uint8
33-60Terminal X59/1 and X59/2 Mode [1] Outpu t 2 set -ups FALSE - Uint8
33-61 Terminal X59/1 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-62 Terminal X59/2 Digital Input [0] No function 2 set- up s TR UE - Ui nt 8
33-63Terminal X59/1 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-64Terminal X59/2 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-65Terminal X59/3 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-66Terminal X59/4 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-67Terminal X59/5 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-68Terminal X59/6 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-69Terminal X59/7 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-70Terminal X59/8 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-8* Global Parameters
33-80Activated Program Number -1 2 set-ups TRUE 0 Int8
33-81Power-up State [1] Motor on 2 set-ups TRUE - Uint8
33-82Drive Status Monitoring [1] On 2 set-ups TRUE - Uint8
33-83Behaviour afterError [0] Coast 2 set-ups TRUE - Uint8
33-84Behaviour afterEsc. [0] Controlled stop 2 set-ups TRUE - Uint8
33-85MCO Supplied by E x ternal 24VDC [0] No 2 set-ups TRUE - Uint8
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
64
MG.33.A7.02 - VLT is a registered Danfoss trademark
