Danfoss FC 300 Operating Instruction

FC 300 Operating Instructions
How to Programme
" 33-** MCO Adv. Settings
Par.
No.
#
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
33-0* Home Motion
33-00Force HOME [0] Home not forced 2 set-ups TRUE - Uint8
33-01Zero Point Offset from Home Pos. 0 2 set-ups TRU E 0 Int32
33-02Ramp for Home Motion 10 2 set-ups TRUE 0 Uint32
33-03Velocity of Home M otion 10 2 set-ups TRUE 0 Int32
33-04Behaviour during HomeMotion [0] Revers and index 2 set-ups TR U E - Uint8
33-1* Sy nchronization
33-10
Synchronization Factor Master
(M:S) 1 2 set-ups TRUE 0 Int32
33-11 Synch ronization Factor Slave (M:S) 1 2 set- ups TR UE 0 Int32
33-12Position Offset for Synchronization 0 2 set-ups TRUE 0 Int32
33-13Accuracy Window for Position Sync. 1000 2 set-ups TRUE 0 Int32
33-14Relative Slave Velocity Limit 0 % 2 set-ups TRUE 0 Uint8
33-15MarkerNumberforMaster 1 2set-ups TRUE 0 Uint16
33-16Marker Number for Slave 1 2 set-ups TRUE 0 Uint16
33-17MasterMarkerDistance 4096 2set-ups TRUE 0 Uint32
33-18Slave Marker Distance 4096 2 set-ups TRUE 0 Uint32
33-19Master Marker Type [0] Encoder Z positive 2 set-ups TRUE - Uint8
33-20Slave Marker Type [0] Encoder Z positive 2 set-ups TRUE - Uint8
33-21MasterMarkerToleranceWindow 0 2set-ups TRUE 0 Uint32
33-22Slave Marker Tolerance Window 0 2 set-ups TRUE 0 Uint32
33-23Start Behaviour for Marker Sync [0] S tart Function 1 2 set-ups TRUE - Uint16
33-24Marker Number for Fault 10 2 set-ups TRUE 0 Uint16
33-25MarkerNumberforReady 1 2set-ups TRUE 0 Uint16
33-26Velocity Filter 0 us 2 set-ups TRUE -6 Int32
33-27Offset Filter Time 0 m s 2 set-ups TRUE -3 U int32
33-28Marker Filter Configuration [0] M arker filter 1 2 set-ups TRUE - Uint8
33-29Filter Tim e for Marker Filter 0 ms 2 set-ups TRUE -3 Int32
33-30Maximum Marker Correction 0 2 set-ups TRUE 0 Uint32
33-31Synchronisation Type [0] Standard 2 set-ups TRUE - Uint8
33-4* Limit Handling
33-40Behaviour atEnd Limit Switch [0] C all error handler 2 set-ups TRUE - Uint8
33-41Negative Software End Limit -500000 2 set-ups TRUE 0 Int32
33-42Positive S oftware End Limit 500000 2 set-ups TRUE 0 Int32
33-43Negative Software End Limit Active [ 0] In active 2 set-ups TRUE - Uint8
33-44Positive Software End Limit Active [0] Inactive 2 set-ups TRUE - Uint8
33-45Time in Target Window 0 ms 2 set-ups TRUE -3 Uint8
33-46Target Window LimitValue 1 2 set-ups TRUE 0 Uint16
33-47Size of Target Window 0 2 set-ups TRUE 0 Uint16
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
63
MG.33.A7.02 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
