Table 12: Mains Cable Size Recommendations, 380–500 V (continued)
Model
code
Frame I
N
[A]
Cable [mm
2
]
Maximum
cable size
[mm
2
]
Maximum
number
of mains
cables
(1)
Hole size of
the mains
terminal
[mm]
Number of
grounding
holes on PE
busbar
Hole size
of the
grounding
terminal
[mm]
iC7-60EA3A
05-658A
571 Cu 2 x (3x150+70)
Al 3 x (3x120+41
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-730A
647 Cu 3 x (3x120+70)
Al 3 x (3x150+70
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-820A
728 Cu 3 x (3x120+70)
Al 4 x (3x120+41
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-880A
AE11 +
IE11
809 Cu 3 x (3x150+70)
Al 4 x (3x120+41
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-1000
905 Cu 4 x (3x120+70)
Al 4 x (3x150+70
Cu)
240 Cu/Al 6 Ø13 5 Ø10.5
iC7-60EA3A
05-1100
2 x AE10 +
2 x IE10
1018 Cu 4 x (3x150+70)
Al 4 x (3x185+57
Cu)
240 Cu/Al 6 Ø13 5 Ø10.5
iC7-60EA3A
05-1260
1148 Cu 6 x (3x95+50)
Al 6 x (3x120+41
Cu)
240 Cu/Al 8 Ø13 8 Ø10.5
iC7-60EA3A
05-1450
1293 Cu 6 x (3x120+70)
Al 6 x (3x150+70
Cu)
240 Cu/Al 8 Ø13 8 Ø10.5
iC7-60EA3A
05-1710
2 x AE11 +
2 x IE11
1453 Cu 6 x (3x150+70)
Al 6 x (3x185+57
Cu)
240 Cu/Al 8 Ø13 8 Ø10.5
1) Cable lugs installed on both sides of the fixing hole
2) With copper cables, use copper lugs. With aluminum cables, use bimetallic lugs.
3) Use bimetallic lugs. No direct aluminum contact to the mains terminals.
4) If the option Top-entry +KCIT is used, the maximum number of mains cables is 4.
5) If the option Top-entry +KCIT is used, the hole size is 13 mm.
