20-00 Feedback 1 Source
Option: Function:
[104] Sensorless Flow Requires set up by MCT 10 Set-up
Software with sensorless specific
plug in.
[105] Sensorless Pressure Requires set up by MCT 10 Set-up
Software with sensorless specific
plug in.
NOTICE
If a feedback is not used, its source must be set to [0] No
Function. Parameter 20-20 Feedback Function determines
how the three possible feedbacks will be used by the
PID Controller.
20-01 Feedback 1 Conversion
Option: Function:
This parameter allows a conversion function
to be applied to Feedback 1.
[0]
*
Linear No effect on the feedback.
[1] Square root Commonly used when a pressure sensor is
used to provide flow feedback
(
flow
∝
pressure
).
[2] Pressure to
temperature
Used in compressor applications to provide
temperature feedback using a pressure sensor.
The temperature of the refrigerant is
calculated using the following formula:
Temperature
=
A
2
ln Pe
+1 −
A
1
−
A
3,
where A1, A2 and A3 are refrigerant-specific
constants. The refrigerant must be selected in
20-30 Refrigerant. Parameter 20-21 Setpoint 1
through 20-23 Setpoint 3 allow the values of
A1, A2 and A3 to be entered for a refrigerant
that is not listed in 20-30 Refrigerant.
[3] Pressure to
flow
Used in applications where the air flow in a
duct is to be controlled. The feedback signal
is represented by a dynamic pressure
measurement (pitot tube).
Flow
=
Duct
Area
×
Dynamic
Pressure
×
Air
Density
Factor
See also 20-34 Duct 1 Area [m2] through
20-38 Air Density Factor [%] for setting of duct
area and air density.
[4] Velocity to
flow
Used in applications where the air flow in a
duct is to be controlled. The feedback signal
is represented by an air velocity
measurement.
Flow
=
Duct
Area
×
Air
Velocity
See also 20-34 Duct 1 Area [m2] through
20-37 Duct 2 Area [in2] for setting of duct area.
20-03 Feedback 2 Source
Option: Function:
See parameter 20-00 Feedback 1
Source for details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input X30/11
[8] Analog Input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[15] Analog Input X48/2
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
[104] Sensorless Flow
[105] Sensorless Pressure
20-04 Feedback 2 Conversion
Option: Function:
See parameter 20-01 Feedback 1
Conversion for details.
[0] * Linear
[1] Square root
[2] Pressure to temperature
[3] Pressure to flow
[4] Velocity to flow
20-06 Feedback 3 Source
Option: Function:
See parameter 20-00 Feedback 1
Source for details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input X30/11
[8] Analog Input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[15] Analog Input X48/2
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
[104] Sensorless Flow
[105] Sensorless Pressure
How to Programme VLT HVAC Drive FC 102 Operating Instructions
104 MG11F402 - Rev. 2013-12-16
