WAS calibration - Mapped max
WA (steering right) at 67% VB
P3837 U8 deg Mapped maximum wheel angle (steering right) at 67% voltage base OEM, Dealer 0 89 60
WAS calibration - Mapped max
WA (steering right) at 100% VB
P3838 U8 deg Mapped maximum wheel angle (steering right) at 100% voltage base OEM, Dealer 0 89 89
WAS calibration - Mapped VB
for max WA (steering right)
P3839 U16 mVolts Mapped voltage base for maximum wheel angle (steering right) OEM, Dealer 0 6000 2000
WAS calibration - Max
allowable CAN WAS signal to
be captured in neutral
P3841 U16 mVolts
Maximum allowed signal to be captured for neutral position during CAN
WAS auto-calibration
OEM, Dealer 0 5000 4500
WAS calibration - Min voltage
needed in between the captured
CAN WAS values
P3843 U16 mVolts
Determines the minimum voltage needed in between the captured CAN
WAS voltage (minimum, neutral and maximum), to ensure a sufficient
high wheel angle resolution during CAN WAS auto-calibration.
OEM, Dealer 0 2500 0
WAS calibration - Min allowable
CAN WAS signal to be captured
in neutral
P3845 U16 mVolts
Minimum allowed signal to be captured for neutral position during CAN
WAS auto-calibration
OEM, Dealer 0 5000 500
Table 77
