Danfoss TMT W FL

Gear Wheel Set Module Number
Nr. Note Item Spare Parts (SAE Version) Code No.
M7 14 Cardan shaft TMT 250 L = 4.29 in 151Z2100
15 Gear wheel set TMT 250 B = 1.23 in
1) 2) 3 O-ring 4.92×0.08 in
Nr. Note Item Spare Parts (SAE Version) Code No.
M7 14 Cardan shaft TMT 315 L = 4.65 in 151Z2101
15 Gear wheel set TMT 315 B = 1.59 in
1) 2) 3 O-ring 4.92×0.08 in
Nr. Note Item Spare Parts (SAE Version) Code No.
M7 14 Cardan shaft TMT 400 L =5.07 in 151Z2102
15 Gear wheel set TMT 400 B = 2.01 in
1) 2) 3 O-ring 4.92×0.08 in
Nr. Note Item Spare Parts (SAE Version) Code No.
M7 14 Cardan shaft TMT 470 L = 5.37 in 151Z2103
15 Gear wheel set TMT 470 B = 2.33 in
1) 2) 3 O-ring 4.92×0.08 in
Nr. Note Item Spare Parts (SAE Version) Code No.
M7 14 Cardan shaft TMT 500 L = 5.07 in 151Z2183
15 Gear wheel set TMT 500 B = 2.01 in
1) 2) 3 O-ring 4.92×0.08 in
Nr. Note Item Spare Parts (SAE Version) Code No.
M7 14 Cardan shaft TMT 630 L = 5.62 in 151Z2184
15 Gear wheel set TMT 630 B = 2.56 in
1) 2) 3 O-ring 4.92×0.08 in
Standard Valve Module Number
Nr. Note Item Spare Parts (SAE Version) Code No.
M8 16 Guide pins ∅0.16×1.57 in 3 pcs 151Z2053
17 Channel plate TMT 250 - TMT 630
18 Valve drive
19 Stop ring
20 Disc valve
1) 2) 3 O-ring 4.92×0.08 in
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT
520L0351 • Rev EA • Feb 2014 13
