Set of Seals and Set of Brake Disc
Code No.
1 Seal set TMT incl. items 2, 3, 22, 23, 24, 25, 35 151B0176
2 Seal set TMT FL incl. items 2, 3, 22, 23, 24, 25, 35, 44, 52, 57 151Z2059
3 Set of brake disc incl. items 50, 51 151Z2069
1) 2) 3) Contained in set of seals and set of brake disc.
Mounting Flange Module
Nr. Note Item (SAE Version) Code No.
M22 61 Gamma ring 49.9×80×7.5 151Z2122
62 Mounting flange
63 Plug 7/16” - 20 UNF
2) 2 Shaft seal 50×72×8
64 O-ring 8×2 mm
42 Stopring Bearing Brake
43 Screw M 6×25 8 pcs.
2) 44 O-ring 171,1×2,6 mm
Plug 7/16” - 20 UNF
Tapered Shaft
Nr. Note Item (SAE Version) Code No.
M23 65 ∅ 45 mm 1 : 10 incl bearing 151Z2039
5 Nut M 30×2 mm
7 Parallel key 28×12×8 mm
8 Washer 56×31×4 mm
48 Brake Orifice-filter
Brake Module Standard
Nr. Note Item (SAE Version) Code No.
M24 3) 51 Outer disc 7 pcs. 11005993
3) 50 Inner disc 6 pcs.
2) 2 Shaft seal 50×72×8
2) 52 O-ring 155×3 mm
53 Piston
66 Disc spring
Motor Flange Module
Nr. Note Item (SAE Version) Code No.
M25 67 with drain port SAE 7/16” - 20 UNF 151Z2123
69 Drain plug (plastic) SAE 7/16” - 20 UNF
2) 3 O-ring 125×2 mm
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT FL
520L0351 • Rev EA • Feb 2014 29
