Mounting Flange Module Number
Nr. Note Item Spare Parts (Metric Version) Code No.
M15 41 Mounting flange with spigot diam ∅180 mm and BC ∅224 mm 151Z2026
2) 2 Shaft seal 50×72×8 mm
42 Stopring Bearing Brake
43 Screw M6×25 8 pcs.
2) 44 O-ring 171.1×2.6 mm
40 Plug G 1/4”
Nr. Note Item Spare Parts (Metric Version) Code No.
M16 46 Mounting flange with spigot diam ∅125 mm and BC ∅160 mm 151Z2170
2) 2 Shaft seal 50×72×8 mm
42 Stopring Bearing Brake
43 Screw M6×25 8 pcs.
2) 44 O-ring 171.1×2.6 mm
45 Plug G 1/4”
Shaft Module Number
Nr. Note Item Spare Parts (Metric Version) Code No.
M17 47 Splined shaft 1.5” incl. bearing 151Z2020
48 Brake Orifice-filter
Nr. Note Item Spare Parts (Metric Version) Code No.
M18 49 Tapered shaft ∅ 45 mm 1 : 10 incl. bearing 151Z2061
5 Nut M 30×2 mm
2) 7 Parallel key 28×12×8 mm
6 Washer 56×31×4 mm
48 Brake Orifice-filter
2) Contained in set of seals - see Spare Part List TMT FL on page 29
Mounting Flange Module Number
Nr. Note Item Spare Parts (SAE Version) Code No.
M15 41 Mounting flange with spigot diam ∅7.09 in and BC ∅8.82 in 151Z2021
2) 2 Shaft seal 1.97×2.83×0.31 in
42 Stopring Bearing Brake
43 Screw M6×0.98 8 pcs.
2) 44 O-ring 6.74×0.10 in
40 Plug 7/16-20 UNF
Nr. Note Item Spare Parts (SAE Version) Code No.
M16 46 Mounting flange with spigot diam ∅5 in and BC ∅6.374 in 151Z2074
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT FL
520L0351 • Rev EA • Feb 2014 23
