Danfoss TMT W FL User Manual

Gear Wheel Set Module Number
Nr. Note Item Spare Parts (Metric Version) Code No.
M7 14 Cardan shaft TMT 250 L = 109 mm 151Z2100
15 Gearwheel set TMT 250 B = 31.2 mm
1) 2) 3 O-ring 125×2 mm
Nr. Note Item Spare Parts (Metric Version) Code No.
M7 14 Cardan shaft TMT 315 L = 118.2 mm 151Z2101
15 Gearwheel set TMT 315 B = 40.5 mm
1) 2) 3 O-ring 125×2 mm
Nr. Note Item Spare Parts (Metric Version) Code No.
M7 14 Cardan shaft TMT 400 L =128.7 mm 151Z2102
15 Gearwheel set TMT 400 B = 51.0 mm
1) 2) 3 O-ring 125×2 mm
Nr. Note Item Spare Parts (Metric Version) Code No.
M7 14 Cardan shaft TMT 470 L = 136.5 mm 151Z2103
15 Gearwheel set TMT 470 B = 59.3 mm
1) 2) 3 O-ring 125×2 mm
Nr. Note Item Spare Parts (Metric Version) Code No.
M7 14 Cardan shaft TMT 500 L = 128.7 mm 151Z2183
15 Gear wheel set TMT 500 B = 51 mm
1) 2) 3 O-ring 125×2 mm
Nr. Note Item Spare Parts (Metric Version) Code No.
M7 14 Cardan shaft TMT 630 L = 142.7 mm 151Z2184
15 Gear wheel set TMT 630 B = 65 mm
1) 2) 3 O-ring 125×2 mm
Standard Valve Module Number
Nr. Note Item Spare Parts (Metric Version) Code No.
M8 16 Guide pins ∅4×40 mm 3 pcs 151Z2053
17 Channel plate TMT 250 - TMT 630
18 Valve drive
19 Stop ring
20 Disc valve
1) 2) 3 O-ring 125×2 mm
1) 2) Contained in set of seals - see Spare Part List TMT FL on page 29
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT
12 520L0351 • Rev EA • Feb 2014
