Danfoss TMT W FL User Manual

Brake Module Number, Standard
Nr. Note Item Spare Parts (Metric Version) Code No.
M19 3) 51 Outer disc 7 pcs. 151Z2023
3) 50 Inner disc 6 pcs.
2) 2 Shaft seal 50×72×8 mm
2) 52 O-ring 55×3 mm
53 Piston
54 Disc spring
Brake Module Number with Back Pressure
Nr. Note Item Spare Parts (Metric Version) Code No.
M20 3) 51 Outer disc 7 pcs. 151Z2068
3) 50 Inner disc 6 pcs.
2) 52 O-ring 155×3 mm
2) 55 Screw M6×12 4 pcs.
56 Stopring
57 Shaft seal 50×72×4.5 mm
58 Piston
54 Disc spring
Motor Flange Module Number
Nr. Note Item Spare Parts (MetricVersion) Code No.
M21 59 Motor flange TMT 250 - 470 with drain port G 1/4 151Z2050
12 Drain plug (plastic) G 1/4”
2) 3 O-ring 125×2 mm
2) 60 Screw M10×40 8 pcs.
Nr. Note Item Spare Parts (Metric Version) Code No.
M21 59 Motor flange TMT 500 - 630 with drain port G 1/4 151Z2197
12 Drain plug (plastic) G 1/4”
2) 3 O-ring 125×2 mm
60 Screw M10×40 8 pcs.
2) 3) Contained in set of seals - see Spare Part List TMT FL on page 29
Brake Module Number, Standard
Nr. Note Item Spare Parts (SAE Version) Code No.
M19 3) 51 Outer disc 7 pcs. 151Z2023
3) 50 Inner disc 6 pcs.
2) 2 Shaft seal 1.97×2.83×0.31 in
2) 52 O-ring 2.17×0.12 in
53 Piston
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT FL
26 520L0351 • Rev EA • Feb 2014
