Danfoss TMT W FL User Manual

Brake Module Number, Standard (continued)
Nr. Note Item Spare Parts (SAE Version) Code No.
54 Disc spring
Brake Module Number with Back Pressure
Nr. Note Item Spare Parts (SAE Version) Code No.
M20 3) 51 Outer disc 7 pcs. 151Z2068
3) 50 Inner disc 6 pcs.
2) 52 O-ring 6.10×0.12 in
2) 55 Screw M6×12 4 pcs.
56 Stopring
57 Shaft seal 1.97×2.83×0.18 in
58 Piston
54 Disc spring
Motor Flange Module Number
Nr. Note Item Spare Parts (SAE Version) Code No.
M21 59 Motor flange TMT 250 - 470 with drain port SAE 9/16-18 UNF 151Z2022
12 Drain plug (plastic) SAE 9/16-18 UNF
2) 3 O-ring 4.92×0.08 in
2) 60 Screw M10×40 8 pcs.
Nr. Note Item Spare Parts (SAE Version) Code No.
M21 59 Motor flange TMT 500 - 630 with drain port SAE 9/16-18 UNF 151Z2196
12 Drain plug (plastic) SAE 9/16-18 UNF
2) 3 O-ring 4.92×0.08 in
60 Screw M10×40 8 pcs.
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT FL
520L0351 • Rev EA • Feb 2014 27
