Flow Restriction Module Number
Nr. Note Item Spare Parts (Metric Version) Code No.
M12 39 Orifice M6 0.6 151Z2106
39 Orifice M6 0.7 151Z2107
39 Orifice M6 0.8 151Z2108
39 Orifice M6 0.9 151Z2109
39 Orifice M6 1.0 151Z2110
39 Orifice M6 1.1 151Z2111
39 Orifice M6 1.2 151Z2112
39 Orifice M6 1.3 151Z2113
39 Orifice M6 1.4 151Z2114
39 Orifice M6 1.5 151Z2115
39 Orifice M6 1.6 151Z2116
39 Orifice M6 1.7 151Z2117
39 Orifice M6 1.8 151Z2118
39 Orifice M6 1.9 151Z2119
39 Orifice M6 2.0 151Z2120
Flushing Valve Module
Nr. Note Item Spare Parts (Metric and SAE Version) Code No.
M12.1 32 Flushing valve
33 Spring 21×5.9 mm 2 pcs.
34 Stop 2 pcs.
1) 2) 35 O-ring 9×1.5 mm
36 Plug G 1/8”
Bolt Module Number, Standard Motors
Nr. Note Item Spare Parts (Metric Version) Code No.
M13 37 TMT 250 M12×180 6 pcs. 151Z2080
38 TMT 250 M12×140 3 pcs.
Nr. Note Item Spare Parts (Metric Version) Code No.
M13 37 TMT 315 M12×190 6 pcs. 151Z2081
38 TMT 315 M12×150 3 pcs.
Nr. Note Item Spare Parts (Metric Version) Code No.
M13 37 TMT 400/500 M12×200 6 pcs. 151Z2082
38 TMT 400/500 M12×160 3 pcs.
Nr. Note Item Spare Parts (Metric Version) Code No.
M13 37 TMT 470 M12×200 6 pcs. 151Z2083
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT
520L0351 • Rev EA • Feb 2014 19
