Nr. Note Item Spare Parts (Metric Version) Code No.
38 TMT 470 M12×160 3 pcs.
Nr. Note Item Spare Parts (Metric Version) Code No.
M13 37 TMT 630 M12×210 6 pcs. 151Z2084
38 TMT 630 M12×170 3 pcs.
Bolt Module Number, Brake Motors
Nr. Note Item Spare Parts (Metric Version) Code No.
M14 61 TMT 250 M12×140 9 pcs. 151Z2090
61 TMT 315 M12×150 9 pcs. 151Z2091
61 TMT 400 M12×160 9 pcs. 151Z2092
61 TMT 470 M12×160 9 pcs. 151Z2093
61 TMT 500 M12×160 9 pcs. 151Z2092
61 TMT 630 M12×170 9 pcs. 151Z2094
Flow Restriction Module Number
Nr. Note Item Spare Parts (SAE Version) Code No.
M12 39 Orifice M6 0.0236 in 151Z2106
39 Orifice M6 0.0276 in 151Z2107
39 Orifice M6 0.0315 in 151Z2108
39 Orifice M6 0.0354 in 151Z2109
39 Orifice M6 0.0393 in 151Z2110
39 Orifice M6 0.0433 in 151Z2111
39 Orifice M6 0.0472 in 151Z2112
39 Orifice M6 0.0512 in 151Z2113
39 Orifice M6 0.0551 in 151Z2114
39 Orifice M6 0.0591 in 151Z2115
39 Orifice M6 0.0630 in 151Z2116
39 Orifice M6 0.0669 in 151Z2117
39 Orifice M6 0.0709 in 151Z2118
39 Orifice M6 0.0748 in 151Z2119
39 Orifice M6 0.0787 in 151Z2120
Flushing Valve Module Number
Nr. Spare Parts (Metric Version) Code No.
M12.1 Flushing Valve with 3 bar spring - thickness 0.8 mm 151Z2138
Flushing Valve with 6 bar spring - thickness 1.0 mm 151Z2212
Flushing Valve with 12 bar spring - thickness 1.2 mm 151Z2222
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT
20 520L0351 • Rev EA • Feb 2014
