Bolt Module Number, Standard Motors
Nr. Note Item Spare Parts (SAE Version) Code No.
M13 37 TMT 250 M12×7.09 6 pcs. 151Z2080
38 TMT 250 M12×5.51 3 pcs.
Nr. Note Item Spare Parts (SAE Version) Code No.
M13 37 TMT 315 M12×7.48 6 pcs. 151Z2081
38 TMT 315 M12×5.90 3 pcs.
Nr. Note Item Spare Parts (SAE Version) Code No.
M13 37 TMT 400/500 M12×7.87 6 pcs. 151Z2082
38 TMT 400/500 M12×6.30 3 pcs.
Nr. Note Item Spare Parts (SAE Version) Code No.
M13 37 TMT 470 M12×7.87 6 pcs. 151Z2083
38 TMT 470 M12×6.30 3 pcs.
Nr. Note Item Spare Parts (SAE Version) Code No.
M13 37 TMT 630 M12×8.27 6 pcs. 151Z2084
38 TMT 630 M12×6.70 3 pcs.
Bolt Module Number, Brake Motors
Nr. Note Item Spare Parts (SAE Version) Code No.
M14 61 TMT 250 M12×5.51 9 pcs. 151Z2090
61 TMT 315 M12×5.90 9 pcs. 151Z2091
61 TMT 400 M12×6.30 9 pcs. 151Z2092
61 TMT 470 M12×6.30 9 pcs. 151Z2093
61 TMT 500 M12×6.30 9 pcs. 151Z2092
61 TMT 630 M12×6.70 9 pcs. 151Z2094
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT
520L0351 • Rev EA • Feb 2014 21
