End Cover Module with Main Port Connection
Nr. Note Item Spare Parts (Metric Version) Code No.
M9 30 G 3/4 and drain port
G 1/4
151Z2121
21 Balance plate
22 Back-up ring, 66.6×1 mm 2 pcs.
2) 23 O-ring 63×2 mm
24 Back-up ring 44.1×1 mm
25 O-ring 40×2 mm
26 Spring 18×3.6 mm 6 pcs.
2) 27 Guide pin 14×5 mm
28 Spacer
29 Main port plug (plastic)
G 3/4 2 pcs.
40 Name plate
29.1 Drain plug (plastic) G 1/4
End Cover Module Number
Nr. Note Item Spare Parts (Metric Version) Code No.
M10 30 End cover with
port connection G 3/4”
151Z2041
21 Balance plate
1) 2) 22 Back-up ring, 66.6×1mm 2 pcs.
1) 2) 23 O-ring 63×2 mm
1) 2) 24 Back-up ring 44.1×1mm
1) 2) 25 O-ring 40×2 mm
26 Spring 18×3.6 mm 6 pcs.
27 Guide pin 14×5 mm
28 Spacer
29 Main port plug (plastic)
3/4” 2 pcs.
40 Name plate
End Cover Module Number prepared for Flushing Valve
Nr. Note Item Spare Parts (Metric Version) Code No.
M11 30 End cover prepared for flushing valve
and port connection G 3/4”
151Z2045
21 Balance plate
1) 2) 22 Back-up ring, 66.6×1mm 2 pcs.
1) 2) 23 O-ring 63×2 mm
1) 2) 24 Back-up ring 44.1×1mm
1) 2) 25 O-ring 40×2 mm
26 Spring 18×3.6 mm 6 pcs.
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT
520L0351 • Rev EA • Feb 2014 15
