End Cover Module Number prepared for Flushing Valve (continued)
Nr. Note Item Spare Parts (Metric Version) Code No.
27 Guide pin 14×5 mm
28 Spacer
29 Main port plug (plastic)
3/4” 2 pcs.
40 Name plate
1) 2) Contained in set of seals - see Spare Part List TMT FL on page 29
End Cover Module with Main Port Connection
Nr. Note Item Spare Parts (SAE Version) Code No.
M9 30 1 1/16” - 12 UN and drain port
9/16” - 18 UF
151Z2042
21 Balance plate
22 Back-up ring, 66.6×1 mm 2 pcs.
2) 23 O-ring 63×2 mm
24 Back-up ring 44.1×1 mm
25 O-ring 40×2 mm
26 Spring 18×3.6 mm 6 pcs.
2) 27 Guide pin 14×5 mm
28 Spacer
29 Main port plug (plastic)
1 1/16” - 12 UN 2 pcs.
40 Name plate
29.1 Drain plug (plastic) 9/16” - 18 UNF
End Cover Module Number
Nr. Note Item Spare Parts (SAE Version) Code No.
M10 30 End cover with
port connection 1 1/16-12 UN
151Z2040
21 Balance plate
1) 2) 22 Back-up ring, 2.62×0.04 in 2 pcs.
1) 2) 23 O-ring 2.48×0.08 in
1) 2) 24 Back-up ring 1.74×0.04 in
1) 2) 25 O-ring 1.57×0.08 in
26 Spring 0.70×0.14 in 6 pcs.
27 Guide pin 0.55×0.20 in
28 Spacer
29 Main port plug (plastic)
1 1/16-12 UN 2 pcs.
40 Name plate
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT
16 520L0351 • Rev EA • Feb 2014
