Nr. Note Item Spare Parts (SAE Version) Code No.
2) 2 Shaft seal 1.97×2.83×0.31 in
42 Stopring Bearing Brake
43 Screw M6×0.98 8 pcs.
2) 44 O-ring 6.74×0.10 in
45 Plug 7/16-20 UNF
Shaft Module Number
Nr. Note Item Spare Parts (SAE Version) Code No.
M17 47 Splined shaft 1.5” incl. bearing 151Z2052
48 Brake Orifice-filter
Repair Instruction Orbital Motors TMT, TMT FL and TMT W FL
Spare Part List TMT FL
24 520L0351 • Rev EA • Feb 2014
