6 Monitor Program Data and Controls
This section provides a detailed description of the forms
and related data and controls that are accessible via the
monitor program’s user interface. The forms are organized
as follows:
• main system
• bearing calibration
• compressor control
• motor monitoring
• magnetic bearing monitor
• electronic valve tuning
• chiller control
• system information
• EEPROM settings
• compressor event log
• history data
• trending
• compressor map
• fault captures
• data captures
6.1 Main System
The “General Data Page” allows the user to quickly view
the following major compressor parameters:
• AC input power
• compressor demand
• shaft speed
• suction temperature/pressure
• discharge temperature/pressure
• IGV % open
To view the “General Data Page”, select “Window” →
“Main System” from the menu bar. Table 4 provides a
description of the “General Data Page” parameters.
The “General Data Page” also plots the following
parameters with respect to time:
• evaporating temperature
• condensing temperature
• power input
• shaft speed
•IGV % Open
• demand
The units used to display the temperature readings depend
on the measurement unit set (Metric: ºC; Imperial: ºF). To
verify or change the measurement unit, refer to section 6.3
"Compressor Control" on page 23. The time displayed
corresponds to the PC system time, and is displayed in
HH:MM format. To clear the graphs, click on the “Reset
Graphs” button.
