Danfoss VACON 1000

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-160-041+GAUL
160
1150
117
840
1910
1250
2888
4750
VACON1000-
ED-180-041+GAUL
180
1290
132
950
1910
1250
2888
4800
VACON1000-
ED-193-041+GAUL
193
1390
141
1010
1910
1250
2888
4850
VACON1000-
ED-215-041+GAUL
215
1540
157
1130
1910
1250
2888
4900
VACON1000-
ED-230-041+GAUL
230
1650
168
1210
4610
1400
2796
5850
VACON1000-
ED-250-041+GAUL
250
1800
183
1310
4610
1400
2796
6150
VACON1000-
ED-265-041+GAUL
265
1900
194
1390
4610
1400
2796
6350
VACON1000-
ED-285-041+GAUL
285
2050
209
1500
4610
1400
2796
6550
VACON1000-
ED-305-041+GAUL
305
2190
223
1600
4610
1400
2796
6850
VACON1000-
ED-325-041+GAUL
325
2340
238
1710
4610
1400
2796
7050
VACON1000-
ED-350-041+GAUL
350
2520
256
1840
4910
1400
2796
7450
VACON1000-
ED-378-041+GAUL
378
2720
277
1990
5410
1400
2796
8200
VACON1000-
ED-408-041+GAUL
408
2930
299
2150
5410
1400
2796
8500
VACON1000-
ED-438-041+GAUL
438
3150
321
2310
5410
1400
2796
9000
VACON1000-
ED-475-041+GAUL
475
3420
348
2500
5410
1400
2796
9400
VACON1000-
ED-515-041+GAUL
515
3710
377
2710
5810
1400
2796
9900
VACON1000-
ED-560-041+GAUL
560
4030
410
2950
5810
1400
2796
10700
VACON1000-
ED-600-041+GAUL
600
4320
440
3170
5810
1400
2796
10950
VACON1000-
ED-640-041+GAUL
640
4610
469
3370
5810
1400
2796
11450
VACON1000-
ED-680-041+GAUL
680
4890
498
3580
5810
1400
2796
11950
