Illustration 6: Controls and Indicators on the Door of the Control Cabinet
A
Line-up cabinet
B
Standalone cabinet
C
HMI
D
Mechanical interlocking system
3.3.2 Power Cell Cabinet
The power cell cabinet contains the power cells and their accessories.
e30bi646.10
A
B
C
Illustration 7: Power Cell Cabinet in VACON® 1000 Standalone Systems
A
Cooling fan
B
Output current Hall sensor
AQ363633621020en-000201 / 172F311718 | Danfoss A/S © 2021.06
Product Overview
VACON® 1000
Operating Guide
