Illustration 2: Line-up System Structure
A
Control cabinet
B
Power cell cabinet
C
Transformer cabinet
D
Junction cabinet
3.3.1 Control Cabinet
The control cabinet includes:
Main control system
PLC
HMI
Battery
Other accessories
