Danfoss VACON 1000 User Manual

Power cell current rating
Fuse model
Fuse rating
170M4813
1000 V AC, 200 A
140 A
170M1372
700 V AC, 315 A
170M2619
700 V AC, 315 A
170M4814
1000 V AC, 250 A
180 A
170M2620
700 V AC, 350 A
215 A
170M2621
700 V AC, 400 A
Table 32: Fuse in Power Cell Cabinet for Lineup Type (Power Cell Current >215 A)
Power cell current rating
Fuse category
Fuse rating
350 A
500FMM or WHFMM
500 A
680 A
700FMM or WHFMM
700 A
Table 33: Fuses in the Start-up Cabinet
Input voltage
Output current rating
Fuse type
2.4 kV, 3 kV, 3.3 kV, 4.16 kV,
210–250 A
A051B2DARO-18R
263–350 A
A051B2DARO-24R
370–438 A
A051B2DARO-32R
460–560 A
A072B3DBRO-48X
588–680 A
A072B3DBRO-57X
6 kV, 6.6 kV, 7.2 kV
210–250 A
A072B2DARO-18R
263–350 A
A072B2DARO-24R
370–438 A
A072B2DORO-32R
460–560 A
A072B3DBRO-48X
588–680 A
A072B3DBRO-57X
Table 34: Fuses in the Control Cabinet
Component ID
Type
Rating
FU11, FU13
Supplemental fuse
600 V AC/ 10 A
FU12
Supplemental fuse
600 V AC/ 15 A
FU14
Supplemental fuse
600 V AC/ 2 A
FU15
Class CC or equivalent
600 V AC/ 1 A
FU16, FU17
Class CC or equivalent
600 V AC/ 20 A
11.5 Standards
AQ363633621020en-000201 / 172F3117136 | Danfoss A/S © 2021.06
Specifications
VACON® 1000
Operating Guide
