Danfoss VACON 1000 User Manual

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight [kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-ED-415-060+GAUL
415
4310
304
3150
6410
1400
2796
11000
VACON1000-ED-438-060+GAUL
438
4550
321
3330
6410
1400
2796
11500
VACON1000-ED-460-060+GAUL
460
4780
337
3500
6410
1400
2796
11950
VACON1000-ED-483-060+GAUL
483
5010
354
3670
6410
1400
2796
12250
VACON1000-ED-507-060+GAUL
507
5260
371
3850
6410
1400
2796
12650
VACON1000-ED-532-060+GAUL
532
5520
390
4050
6610
1400
2796
13150
VACON1000-ED-560-060+GAUL
560
5810
410
4260
6610
1400
2796
13750
VACON1000-ED-588-060+GAUL
588
6110
431
4470
6610
1400
2796
14100
VACON1000-ED-617-060+GAUL
617
6410
452
4690
6610
1400
2796
14500
VACON1000-ED-648-060+GAUL
648
6730
475
4930
7210
1600
2796
15100
VACON1000-ED-680-060+GAUL
680
7060
498
5170
7210
1600
2796
15500
Table 27: Nominal Voltage 6300 V, 36-pulse, 6 Power Cells per Phase, 60 Hz
AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight [kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-025-063+GAUL
25
270
18
190
2310
1250
2796
3600
VACON1000-
ED-030-063+GAUL
30
310
22
220
2310
1250
2796
3620
VACON1000-
ED-036-063+GAUL
36
370
26
270
2310
1250
2796
3625
VACON1000-
ED-045-063+GAUL
45
460
33
340
2310
1250
2796
3640
VACON1000-
ED-050-063+GAUL
50
510
36
370
2310
1250
2796
3650
VACON1000-
ED-065-063+GAUL
65
670
47
480
2310
1250
2796
3675
VACON1000-
ED-070-063+GAUL
70
720
51
530
2310
1250
2796
3700
VACON1000-
ED-085-063+GAUL
85
880
62
640
2710
1250
2888
4950
VACON1000-
ED-100-063+GAUL
100
1030
73
750
2710
1250
2888
5000
VACON1000-
ED-115-063+GAUL
115
1190
84
870
2710
1250
2888
5050
AQ363633621020en-000201 / 172F3117 | 127Danfoss A/S © 2021.06
Specifications
VACON® 1000
Operating Guide
