5.1.8 Quick Transfer of Parameter Settings
with the LCP
Once the set-up is complete, store (back up) the parameter
settings in the LCP or on a PC via MCT 10 set-up software
tool.
WARNING
Running the unit during these operations can cause
unexpected operation. Stop the unit before performing
any of these operations. Failure to do so can cause
damage or injury..
Data storage in LCP
1.
Go to 0-50 LCP Copy.
2. Press [OK].
3.
Select [1] All to LCP.
4. Press [OK].
All parameter settings are now stored in the LCP indicated
by the progress bar. When 100% is reached, press [OK].
The LCP can now be connected to another active filter and
the parameter settings copied to this active filter.
Data transfer from LCP to the unit
1.
Go to 0-50 LCP Copy.
2. Press [OK].
3.
Select [2] All from LCP.
4. Press [OK].
The parameter settings stored in the LCP are now
transferred to the active filter indicated by the progress
bar. When 100% is reached, press [OK].
5.1.9
Initialisation to Default Settings
There are 2 ways to initialise the unit to default:
Recommended initialisation and manual initialisation.
Each method has a different impact.
5.1.9.1
Recommended Initialisation Method
Initialisation via 14-22 Operation Mode
1.
Select 14-22 Operation Mode.
2. Press [OK].
3.
Select Initialisation.
4. Press [OK].
5. Remove power to the unit and wait for the
display to turn off.
6. Reconnect power to reset the unit.
7. Press [Reset].
14-22 Operation Mode
initialises all except:
•
Parameter 14-50 RFI Filter.
•
8-31 Address.
•
8-32 Baud Rate
•
8-35 Minimum Response Delay
•
Parameter 8-36 Max Response Delay
•
8-37 Maximum Inter-Char Delay
•
Parameter 15-00 Operating hours to
parameter 15-05 Over Volt's
•
Parameter 15-20 Historic Log: Event to
parameter 15-22 Historic Log: Time
•
15-30 Alarm Log: Error Code to
parameter 15-32 Alarm Log: Time
NOTICE
Parameters selected in 0-25 My Personal Menu, stay
present with default factory setting.
5.1.9.2 Manual Initialisation Method
NOTICE
When carrying out manual initialisation, serial communi-
cation, RFI filter settings, and fault log settings are reset.
Manual initialisation removes parameters selected in
0-25 My Personal Menu.
1. Disconnect from mains and wait until the display
turns off.
2. Press [Status] - [Main Menu] - [OK] at the same
time during power-up for graphical LCP .
3. Release the keys after 5 s.
4. The unit is now programmed according to default
settings.
This parameter initialises all except:
•
Parameter 15-00 Operating hours
•
Parameter 15-03 Power Up's
•
Parameter 15-04 Over Temp's
•
Parameter 15-05 Over Volt's
User Interface
Operating Instructions
34 Danfoss A/S © 09/2014 All rights reserved. MG90V302
