6.12.5 14-** Special Functions
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
14-2* Trip Reset
14-20 Reset mode [0] Manual reset All set-ups TRUE - Uint8
14-21 Automatic restart time 10 s All set-ups TRUE 0 Uint16
14-22 Operation mode [0] Normal operation All set-ups TRUE - Uint8
14-23 Typecode setting null 2 set-ups FALSE - Uint8
14-28 Production settings [0] No action All set-ups TRUE - Uint8
14-29 Service code 0 N/A All set-ups TRUE 0 Int32
14-5* Environment
14-50 RFI filter [1] On 1 set-up FALSE - Uint8
14-53 Fan monitor [1] Warning All set-ups TRUE - Uint8
14-54 Bus partner 1 N/A 2 set-ups TRUE 0 Uint16
6.12.6 15-** FC Information
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
15-0* Operating Data
15-00 Operating hours 0 h All set-ups FALSE 74 Uint32
15-01 Running hours 0 h All set-ups FALSE 74 Uint32
15-03 Power up's 0 N/A All set-ups FALSE 0 Uint32
15-04 Over temp's 0 N/A All set-ups FALSE 0 Uint16
15-05 Over volt's 0 N/A All set-ups FALSE 0 Uint16
15-07 Reset running hours counter [0] Do not reset All set-ups TRUE - Uint8
15-1* Data Log Settings
15-10 Logging source 0 2 set-ups TRUE - Uint16
15-11 Logging interval ExpressionLimit 2 set-ups TRUE -3 TimD
15-12 Trigger event [0] False 1 set-up TRUE - Uint8
15-13 Logging mode [0] Log always 2 set-ups TRUE - Uint8
15-14 Samples before trigger 50 N/A 2 set-ups TRUE 0 Uint8
15-2* Historic Log
15-20 Historic log: Event 0 N/A All set-ups FALSE 0 Uint8
15-21 Historic log: Value 0 N/A All set-ups FALSE 0 Uint32
15-22 Historic log: Time 0 ms All set-ups FALSE -3 Uint32
15-3* Fault Log
15-30 Fault log: Error code 0 N/A All set-ups FALSE 0 Uint16
15-31 Fault log: Value 0 N/A All set-ups FALSE 0 Int16
15-32 Fault log: Time 0 s All set-ups FALSE 0 Uint32
15-4* Unit Identification
15-40 FC type 0 N/A All set-ups FALSE 0 VisStr[6]
15-41 Power section 0 N/A All set-ups FALSE 0 VisStr[20]
15-42 Voltage 0 N/A All set-ups FALSE 0 VisStr[20]
15-43 Software version 0 N/A All set-ups FALSE 0 VisStr[5]
15-44 Ordered typecode string 0 N/A All set-ups FALSE 0 VisStr[40]
15-45 Actual typecode string 0 N/A All set-ups FALSE 0 VisStr[40]
15-46 Unit ordering number 0 N/A All set-ups FALSE 0 VisStr[8]
15-47 Power card ordering number 0 N/A All set-ups FALSE 0 VisStr[8]
15-48 LCP ID number 0 N/A All set-ups FALSE 0 VisStr[20]
15-49 SW ID control card 0 N/A All set-ups FALSE 0 VisStr[20]
