6.12.8 300-** AF Settings
NOTICE
Except for parameter 300-10 Active Filter Nominal Voltage, it is not recommended to change the settings in this
parameter group.
Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
300-0* General Settings
300-00 Harmonic cancellation mode [0] Overall All set-ups TRUE - Uint8
300-01 Compensation priority [0] Harmonics All set-ups TRUE - Uint8
300-08 Lagging reactive current [0] Disabled All set-ups
300-1* Network Settings
300-10 Active filter nominal voltage ExpressionLimit 2 set-ups FALSE 0 Uint32
300-2* CT Settings
300-20 CT primary rating ExpressionLimit 2 set-ups FALSE 0 Uint32
300-22 CT nominal voltage 342 V 2 set-ups FALSE 0 Uint32
300-24 CT sequence [0] L1, L2, L3 2 set-ups FALSE - Uint8
300-25 CT polarity [0] Normal 2 set-ups FALSE - Uint8
300-26 CT placement [1] Load Current 2 set-ups FALSE - Uint8
300-29 Start auto CT detection [0] Off All set-ups FALSE - Uint8
300-3* Compensation
300-30 Compensation points 0.0 A All set-ups TRUE -1 Uint32
300-35 Cosphi reference 0.500 N/A All set-ups TRUE -3 Uint16
300-4* Paralleling
300-40 Master follower selection [2] Not Paralleled 2 set-ups FALSE - Uint8
300-41 Follower ID 1 N/A 2 set-ups FALSE 0 Uint32
300-42 Number of follower AFs 1 N/A 2 set-ups FALSE 0 Uint32
300-5* Sleep Mode
300-50 Enable sleep mode null 2 set-ups TRUE - Uint8
300-51 Sleep mode trig source [0] Mains current All set-ups TRUE - Uint8
300-52 Sleep mode wake up trigger ExpressionLimit All set-ups TRUE 0 Uint32
300-53 Sleep mode sleep trigger 80 % All set-ups TRUE 0 Uint32
6.12.9 301-** AF Readouts
Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
301-0* Output Currents
301-00 Output current [A] 0.00 A All set-ups TRUE -2 Int32
301-01 Output current [%] 0.0 % All set-ups TRUE -1 Int32
301-1* Unit Performance
301-10 THD of current [%] 0.0 % All set-ups TRUE -1 Uint16
301-11 Estimated THD of voltage [%] 0.0 % All set-ups Uint16
301-12 Power factor 0.00 N/A All set-ups TRUE -2 Uint16
301-13 Cosphi 0.00 N/A All set-ups TRUE -2 Int16
301-14 Leftover currents 0.0 A All set-ups TRUE -1 Uint32
301-2* Mains Status
301-20 Mains current [A] 0 A All set-ups TRUE 0 Int32
301-21 Mains frequency 0 Hz All set-ups TRUE 0 Uint8
301-22 Fund. mains current [A] 0 A All set-ups TRUE 0 Int32
Applications and Basic Prog... Operating Instructions
68 Danfoss A/S © 09/2014 All rights reserved. MG90V302
