6.11 301-** AF Readouts
301-00 Output Current [A]
Range: Function:
0.00 A* [0.00 - 10000.00 A] View the RMS output current of
the unit.
301-01 Output Current [%]
Range: Function:
0.0 %* [0.0 - 10000.0 %] View the RMS output current of the
unit, expressed as a percentage of the
nominal current.
301-10 THD of Current [%]
Range: Function:
0 %* [0 - 200 %] View the total harmonic distortion of the
current.
301-11 Estimated THD of Voltage [%]
Range: Function:
0 %* [0 - 200 %] View the total harmonic distortion of the
voltage. This value is estimated because the
active filter does not measure the mains
voltage.
301-12 Power Factor
Range: Function:
0.00* [0.00 - 2.00 ] View the power factor after compensation
by the active filter.
301-13 Cosphi
Range: Function:
0.00* [-1.00 -
2.00 ]
View the displacement power factor, after
compensation by the active filter. Positive
numbers indicate a leading power factor,
while negative numbers indicate a lagging
power factor.
301-14 Leftover Currents
Range: Function:
0.0 A* [0.0 - 8000.0 A] View the harmonic currents left over
after prioritised harmonic and cosphi
compensation by the active filter.
301-20 Mains Current [A]
Range: Function:
0 A* [0 - 65000 A] View the total harmonic distortion of the
current after compensation by the active
filter.
301-21 Mains Frequency
Range: Function:
0 Hz* [0 - 100 Hz] View the total harmonic distortion of the
voltage.
301-22 Fund. Mains Current [A]
Range: Function:
0 A* [0 - 65000 A] View the power factor, after compensation
by the active filter.
Applications and Basic Prog... Operating Instructions
MG90V302 Danfoss A/S © 09/2014 All rights reserved. 61
6 6
