6.12.3 5-** Digital In/Out
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
5-0* Digital I/O mode
5-00 Digital I/O mode [0] PNP All set-ups FALSE - Uint8
5-01 Terminal 27 mode [0] Input All set-ups TRUE - Uint8
5-02 Terminal 29 mode [0] Input All set-ups TRUE - Uint8
5-1* Digital Inputs
5-10 Terminal 18 digital input [8] Start All set-ups TRUE - Uint8
5-11 Terminal 19 digital input [0] No operation All set-ups TRUE - Uint8
5-12 Terminal 27 digital input [0] No operation All set-ups TRUE - Uint8
5-13 Terminal 29 digital input [0] No operation All set-ups TRUE - Uint8
5-16 Terminal X30/2 digital input [0] No operation All set-ups TRUE - Uint8
5-17 Terminal X30/3 digital input [0] No operation All set-ups TRUE - Uint8
5-18 Terminal X30/4 digital input [0] No operation All set-ups TRUE - Uint8
5-19 Terminal 37 Safe stop [1] Safe Stop Alarm 1 set-up TRUE - Uint8
5-3* Digital Outputs
5-30 Terminal 27 Digital output [0] No operation All set-ups TRUE - Uint8
5-31 Terminal 29 Digital output [0] No operation All set-ups TRUE - Uint8
5-4* Relays
5-40 Function relay [0] No operation All set-ups TRUE - Uint8
5-41 On delay, relay 0.30 s All set-ups TRUE -2 Uint16
5-42 Off delay, relay 0.30 s All set-ups TRUE -2 Uint16
6.12.4 8-** Comm. and Options
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
8-0* General Settings
8-01 Control site [0] Digital and ctrl.word All set-ups TRUE - Uint8
8-02 Control word source null All set-ups TRUE - Uint8
8-03 Control word timeout time 1.0 s 1 set-up TRUE -1 Uint32
8-04 Control word timeout function [0] Off 1 set-up TRUE - Uint8
8-05 End-of-timeout Function [1] Resume set-up 1 set-up TRUE - Uint8
8-06 Reset control word timeout [0] Do not reset All set-ups TRUE - Uint8
8-3* FC Port Settings
8-30 Protocol [1] FC MC 1 set-up TRUE - Uint8
8-31 Address 2 N/A 1 set-up TRUE 0 Uint8
8-32 FC port baud rate [2] 9600 Baud 1 set-up TRUE - Uint8
8-35 Minimum response delay 10 ms All set-ups TRUE -3 Uint16
8-36 Max response delay 5000 ms 1 set-up TRUE -3 Uint16
8-37 Max Iiter-char delay 25 ms 1 set-up TRUE -3 Uint16
8-5* Digital/Bus
8-53 Start select [3] Logic OR All set-ups TRUE - Uint8
8-55 Set-up select [3] Logic OR All set-ups TRUE - Uint8
